PRODUCT OVERVIEW
This is a small, cost-effective 1 GHz or 1000 MHz High Pass Filter. Typical insertion loss is less than 0.5 dB from 1 GHz to 2 GHz. The filter provides excellent power handling of up to a maximum 2W or +33 dBm and has an operating temperature range of -40C to +85C.
APPLICATIONS
- Suppression of strong signals in HF, VHF and UHF Bands
SPECIFICATIONS
| FREQUENCY (MHz) | ATTENUATION |
| 50 | 55 dB |
| 200 | 55 dB |
| 400 | 65 dB |
| 600 | 40 dB |
| 700 | 50 dB |
| 900 | 3 dB |
| 1000 | 0..5 dB |
| 2000 | 0.5 dB |
| 2700 | 2.5 dB |
| 3000 | 2.5 dB |
NOTE: The filter uses SMA-F connectors.
